| 通道 | 8通道 |
| 輸入范圍 | mA, T/C: J, K, T, E, R, S, B type |
| 輸入類型 | Type J (0~760° C)
Type K (0~1370° C)
Type T (-100~400° C)
Type E (0~1000° C)
Type R (500~1750° C)
Type S (500~1750° C)
Type B (500~1800° C)
±20 mA, 4~20 mA |
| 分辨率(Bits) | 16-bit |
| 采樣率（S/s ） | 10 S/s (sum) |
| 通信方式 | RS-485 |
| 隔離電壓 | 3000 VDC |
| 運行溫度 | -10~70 °C (14~158 °F) |
| 連接器 | 2 x 10-pin plug-in screw terminal |
| 協議 | ASCII command, Modbus/RTU |
| 電源要求 | 10~30 VDC |
